Electric Rim Locks
Model | OB500H | OB500HA |
Operating Voltage | 12VDC or 24VDC | |
Working current | 12V/400mA or 24V/200mA | |
Operating temperature | -25 ℃~60 ℃ | |
Working humidity | 10%~90%RH | |
Way of unlock | Power off to unlock | |
Installation method | Hanging installation (Surface installation) | |
Force of pull | 500KG | |
Door opening angle | 90° | |
Panel material | High strength aluminum alloy | |
Finish | Oxidation & brushed finishing | |
Signal feedback | no | yes |
Indicator light | yes | |
Delay adjustment | no | |
Standard sizes | 267*73*42 mm | |
Scope of application | Wooden door, Glass door, Metal door | |
